LG LCD Monitor TV Video Wall HD 1920x1080P for Security Monitoring Center
Description:
1: Narrow bezel between screens, thin bezel between screen after combine is 20mm
2: Input and output interfaces ensure the product application with maximum compatibility and flexibility.
3: All metal casing. Anti-static, anti magnetic-field and tamper-proof.
4: The green environmental protection design
Specifications:
|
Specifications
|
|
Model No.
|
TYL-DID4209
|
|
Screen size
|
LG 42inch lcd screen
|
|
Aspect Ratio
|
16:9
|
|
Resolution
|
1920*1080
|
|
Bezel width
|
20mm
|
|
Brightness (nits)
|
500cd/m2
|
|
Contrast
|
4000:1
|
|
Visual angle (H/V)
|
178°
|
|
Response time
|
<=8ms
|
|
Life(hrs)
|
>60,000(hrs)
|
|
Input and output
|
|
BNC out
|
1
|
|
BNC in
|
2
|
|
VGA in
|
1
|
|
HDMI in
|
1
|
|
DVI in
|
1
|
|
YPBPR in
|
1
|
|
Power
|
|
Power supply
|
AC100V~240V
|
|
Maximum power consumption
|
170W
|
|
Standby power consumption
|
<=3W
|
|
Temperature
|
|
Working temperature
|
0°C~50°C
|
|
Working humidity
|
20%-80%
|
|
Appearance
|
|
Panel dimension( W x H x D) mm
|
957.5(L)*550.2(H)*120.7(D)mm
|
|
Acessory
|
|
Cable
|
Can supply different kinds of cable
|
|
Video Wall Controller(Built-in each screen)
|
|
Model No.
|
TYL-DP4609
|
|
Input
|
DVI
|
1*DVI
|
|
HDMI
|
1*HDMI
|
|
VGA
|
1*VGA, 15port, support SVGA/XGA/WXGA
|
| BNC |
2*BNC input, support PAL/ NTSC all formats |
|
RS232
|
1*RS232 (RJ45)
|
| Output |
RS232 |
1*RS232 (RJ45) |
|
Output
|
BNC
|
1*BNC, support PAL/ NTSC all formats
|
|
Operate mode
|
Panel key operation(needs customization)
|
|
Standard RS232 port( provide free control software)
|
|
Infrared Remote Control Operation
|
|
Engineering software
|
Customized
|
|
Working temperature
|
0~70 °C
|
|
working humidity
|
5~95 %RH
|
|
AC voltage power supply
|
100-240V/50, 60Hz
|
|
power consumption
|
50W
|
|
Weight
|
About 3.5KG
|
|
|
|
|
|
Applications:
entertaiment bar,cinima and ktv,school and book shop,medical industry,working building,meeting room,toll stations,parks,ticket agencies,HR markets,model rooms,Security Monitoring Center, Surveillance,Show Center,Rental and advertising Center,Mass Info Display systems,Retail Shopping Mall Advertising,Public Installations
Why choose Weiguan Views:
1: We provide excellent customer service for pre-sale/on sale/after sale orders.
2: Unique DNX motion supplement image processing technology, Dynamic image without motion trail,Splicing image processing RS-232(RJ-45)loop-circuit input/output.,
3: Professional service and honesty based. Reply your inquiry in 8 working hours.
4: Fast delivery. For standard model, sample is usually in stock. It can be shipped immediately after payment confirmation.
