automatic solar tracker

one-axis solar energy tracking system used power sun with solar panels

Quick Detail:

Application: Home or street lamp
Output Voltage (V): DC12V -DC24V
Load Power (W) LED: 30 W-120W
Solar Power (W): 100W -400W

Specifications:

1. Automatic tracking mode: Biaxial automatic
2. Weight of the entire system (excluding solar ): 18kg
3. Of vertical angle (angle of elevation)0° ~ +90°
4. Horizontal angle range (azimuth): 0~355°
5. Principle: Active
6. Precision: ± 1°
7. Annual average power generation volume: ≥45%
8. System average power consumption W: 0.5
9. Protection: Wind, automatic protection

Technical parameters:

Solar Tracking System is a device for orienting a solar panel or concentrating a solar reflector or lens towards the sun. Concentrators, especially in solar cell applications, require a high degree of accuracy to ensure that the concentrated sunlight is directed precisely to the powered device. Precise tracking of the sun is achieved through systems with single or dual axis tracking.

System composition:

RY-SL-B  multi-axial sun tracking system by solar  sensors, controller and transmission actuators three parts.

1, solar sensor

In effective the whole lighting conditions for high accuracy measurement, and sunshine sunshine azimuth signal into electrical signal, send tracking controller.

 2, controller

Tracking controller receives the sun after the signal tracking sensors, driving the transmission actuators operation, and make solar panels is perpendicular to the sun's rays.

3, Transmission actuators:

Adopt unique mechanical structure design, realizing horizontal 360 °, 180 ° pitch Angle can adjust fixed, the biggest after wind could reach 10 levels

Single axis trackers have one degree of freedom that acts as an axis of rotation. The axis of rotation of single axis trackers is typically aligned along a true North meridian. It is possible to align them in any cardinal direction with advanced tracking algorithms.

There are several common implementations of single axis trackers. These include horizontal single axis trackers (HSAT), horizontal single axis tracker with tilted modules (HTSAT), vertical single axis trackers (VSAT), tilted single axis trackers (TSAT) and polar aligned single axis trackers (PSAT). The orientation of the module with respect to the tracker axis is important when modeling performance.

Why Solar Tracking Systems:

Global warming has increased the demand and request for green energy produced by renewable sources such as solar power. Consequently, solar tracking is increasingly being applied as a sustainable power generating solution.

Solar Tracking System is a device for orienting a solar panel or concentrating a solar reflector or lens towards the sun. Concentrators, especially in solar cell applications, require a high degree of accuracy to ensure that the concentrated sunlight is directed precisely to the powered device. Precise tracking of the sun is achieved through systems with single or dual axis tracking.

Application scope:

• Power generation systems: rooftop solar power station,
• Solar heating system: solar boiled water machine, heating system, integrating thermal engineering,
• Outdoor lighting: the solar street lamps, highway LED screen, outdoor media advertising box, highway crossing traffic light, telecom mobile base station power supply system,
• Civil system: household small power systems, nomadic life electricity, border posts/control box.
