600W Rooftop Solar Power Off Grid System With Automatic Overload Protection

Large Image : 600W Rooftop Solar Power Off Grid System With Automatic Overload Protection

Product Details:

Place of Origin:	China
Brand Name:	CESC
Certification:	CE TUV
Model Number:	CESC-KGP600

Payment & Shipping Terms:

Minimum Order Quantity:	50 Units
Price:	Negotiation
Packaging Details:	Wooden & Carton Package
Delivery Time:	12 working days
Payment Terms:	TT or LC at sight
Supply Ability:	5000 units per month

Contact Now

Detailed Product Description

Product Name:	600W Off Grid Solar Power System	Output Power:	600W
Output Voltage:	220Vac Or 110Vac	Solar Panel Power:	300W * 2 Pcs
Highlight:	residential solar power systems

Roof Installation 600W Off Grid Solar Power System For Solar Home Power System

Features

Our solar power system have those functions and characteristics as following:

1. More higher generate efficiency than the traditional solar power system;

2. 100% rate output power, Pure sine wave output ;

3. Automatic recognition and selection of solar energy work mode or city grid operation mode

4. Solar generate real time using function

5. The solar energy complementary control function

6. The City grid complementary control function

7. AVR City-grid voltage stabilizing function, Wide voltage input : AC140V-AC280V

8. Unattended, automatic recovery function

a. Undervoltage protection and undervoltage automatic recovery function

b. overvoltage protection and overvoltage automatic recovery function

c. Solar reverse connection protection

d. Automatic protection when short circuit

e. Automatic overload protection

9. LCD intelligent display

Specification

ITEM	SPECIFICATION:
SOLAR PANEL	TYPE NO:		P3Y-150
	QTY:		2pcs
	CONNECT ARRAY:		2pcs in parallel
	SPEC:	CELLS:	156mm polysilicon cells*72
		Pm(Wp):	150W
		Vm(V):	18V
		Im(A):	8.33A
		Voc(V):	22.5
		Isc(A):	9.08A
		size(MM):	147068035MM
		N.W(KG):	12KG
SOLAR BRACKET	Material:		aluminum
	SPEC:		1*2,suit for solar panels array
	Install place:		steel roof
POWER BOX	TYPE NO:		CESC-KGP600
	CONTROLLER:	Controller Mode:	PWM
		Solar panel input range:	DC15V-DC30V
		Rated voltage of solar input:	DC18V
		Floating charge voltage:	14.5V
		Charging voltage:	12V DC
		Charging current:	30A
		Efficiency:	96% (Max)
	INVERTER:	Rated Output Power:	600W
		Peak power:	200% * 1s
		Working Efficiency:	>83%
		Output Wave:	Pure Sine Wave(THD≤5%)
		Output vltage:	220V50HZ/110V60HZ
		Grid power input:	220V50HZ/110V60HZ
		Switching Time:	≤4 ms (between grid and inverter)
		Protection Functions:	DC over-voltage protection/over-voltage self-revcovery
			DC low-voltage protection/low-voltage self-revcovery
			Overheat/short-current/overload protection
		Features:	AVR Functions:AC145V-275V(input), AC198V-242V (output)
			AVR Functions:AC145V-275V(input), AC198V-242V (output)
			batteries can be charged by Grid and automatic supply power when Grid cut off

	BATTERY	Battery Type:	Maintain-free Lead-acid battery
		Capaticty:	12V/100AH*1 (Max:1200WH)
		system voltage:	12V DC
		N.W:	30kg
	Size:		530mm×262mm×520mm(with wheel)
	N.W:		25.7kg(do not include battery)
OTHERS ACCESSORIES	PV CABLE:	SPEC&QTY:	4mm sq with MC4 connectors: 30m

Power Consumption for reference :

Appliance	Rated Power(W)	QTY (PCS)	Daily Wokring Time (H)	Daily Power Consumption(WH)
LED Lamps	3	5	6	90
Satellite Receiver	25	1	2	50
LCD TV	70	1	4	280
DVD	40	1	2	80
FAN	40	2	6	480
Total	230	W		980
