Low Frequency 30 KVA 380V Online Uninterruptible Power Supply UPS Systems

Large Image : Low Frequency 30 KVA 380V Online Uninterruptible Power Supply UPS Systems

Product Details:

Place of Origin:	China
Brand Name:	Modern
Certification:	ISO 9001
Model Number:	BUD

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	negotiation
Packaging Details:	Wooden Packing
Delivery Time:	30 days
Payment Terms:	T/T
Supply Ability:	1000 unit/month

Contact Now

Detailed Product Description

Highlight:	uninterruptible power supply system

30KVA 380V Uninterruptible Power Supply (Online type UPS)

Quick Detail:

Online Type UPS-5KVA to 200KVA

Dimension(W×D×H)mm: 800×600×2260(1or2 cabinet)

Weight: 450kg

Description:

In the event of an AC power failure, the UPS will automatically transfer to battery power and continue to provide power without any interruption for the full amount of time you select. When power returns, the UPS will automatically recharge the batteries for the next unexpected power outage or disturbance.

MODERN BUD Series Industrial UPS are for the bad grid environment and the impact of power system load on the power requirements of high reliability, using the most advanced multi-CPU control technology developed by frequency pure-line intelligent UPS. MODERN UPS advantage lies in ultra-high-power design; single maximum power 750kVA, and in parallel multi-machine power up to 3000kVA, providing critical power protection for a range of applications.

Applications:

Computer and data centers
Broadcasting and telecommunication
Industrial process manufacturing
Medical equipment and healthcare facilities
Education and research
Transport systems
Emergency lighting systems
Financial systems and services
Any areas needing critical power management

Specifications:

Model

BUD220

-3050

BUD220

-3100

BUD220

-3150

BUD220

-3300

BUD220

-3500

BUD220

-31000

BUD220

-32000

DC Input

Rated Input Voltage (V)

220

Rated Input Current (A)

25.3

49.4

148

247

494

988

Input DC Voltage Range (V)

180 ～ 300

AC Input

Rating Input Voltage (V)

220 ( Single-phase )

380 (3 phase 4 wires)

Voltage Range (V)

220 ± 15%

380 ± 15%

Input Frequency (Hz)

45 ～ 60

Power Factor (PF)

0.9

Bypass Input

Input Voltage Range (V)

380 ± 15% (3 phase 4 wires)

Rated Input Current (A)

7.6

15.2

22.8

45.6

152

304

AC Output

Rated Capacity (KVA)

100

200

Rated Output Power (KW)

160

Rated Output Voltage

380VAC , 50Hz (3 phase 4 wires)

Rated Output Current (A)

7.6

15.2

22.8

45.6

152

304

Output Voltage Accuracy (V)

380 ± 3%

Output Frequency Accuracy (Hz)

50 ± 0.05

Waveform Deviation Factor
(THD) - Liner Load

≤ 5%

Three-Phase load Unbalance Ability

≤ 100%

Dynamic Response
( load 0 ←→ 100%)

Power Factor (PF)

0.8

Load ability

150%,10 seconds

Crest Factor (CF)

3:1

Inverted Efficiency
(80% resistance load )

92%

Switch Time
(ms)

AC ⇋ DC

Inverter ⇋ Bypass

Working Environment

Insulation Strength

2000V AC ,1 minute

Noise (1 meter)

≤ 50dB

Using Condition Temperature

-10 ℃ ~+ 50 ℃

Humidity

0~90%, no condensing

Using Altitude (m)

≤ 2000

Machine Dimension

Width×Depth×Height(mm)

550×485×1200

800×600×2260
(1 or 2 cabinet)

1000×800 × 2260
(1 or 2 cabinet)

Reference Weight (Kg)

200

250

450

620

950

2300

Fault dry contact

Inverter abnormal,AC abnormal,battry abnormal,

load abnormal,UPS abnormal

Protection function

Input reversing protection,input low-voltage protection,

output over-load protection,output short-circuit protection,

over-heat protection

Competitive Advantage:

Adopt power standard screen tank design
High output power factor diminishes need for UPS over sizing
Constant high efficiency at full and partial load
Extremely low output distortion
Best in class for variable load applications
Galvanic isolation which provide additional critical power protection
Municipal electric power supply with DC inverter power 0 conversion delay
Adopt DSP digital control technology intelligent detection and monitoring function
High-speed IGBT drive inverter
No fountain contact and RS232/485 monitoring
